#kubernetes etcd backup and restore | Explore Tumblr posts and blogs

computingpostcom · 2 years ago

Text

In recent years, the popularity of Kubernetes and its ecosystem has immensely increased due to its ability to its behavior, ability to design patterns, and workload types. Kubernetes also known as k8s, is an open-source software used to orchestrate system deployments, scale, and manage containerized applications across a server farm. This is achieved by distributing the workload across a cluster of servers. Furthermore, it works continuously to maintain the desired state of container applications, allocating storage and persistent volumes e.t.c. The cluster of servers in Kubernetes has two types of nodes: Control plane: it is used to make the decision about the cluster(includes scheduling e.t.c) and also to detect and respond to cluster events such as starting up a new pod. It consists of several other components such as: kube-apiserver: it is used to expose the Kubernetes API etcd: it stores the cluster data kube-scheduler: it watches for the newly created Pods with no assigned node, and selects a node for them to run on. Worker nodes: they are used to run the containerized workloads. They host the pods that er the basic components of an application. A cluster must consist of at least one worker node. The smallest deployable unit in Kubernetes is known as a pods. A pod may be made up of one or many containers, each with its own configurations. There are 3 different resources provided when deploying pods in Kubernetes: Deployments: this is the most used and easiest resource to deploy. They are usually used for stateless applications. However, the application can be made stateful by attaching a persistent volume to it. StatefulSets: this resource is used to manage the deployment and scale a set of Pods. It provides the guarantee about ordering and uniqueness of these Pods. DaemonSets: it ensures all the pod runs on all the nodes of the cluster. In case a node is added/removed from the cluster, DaemonSet automatically adds or removes the pod. There are several methods to deploy a Kubernetes Cluster on Linux. This includes using tools such as Minikube, Kubeadm, Kubernetes on AWS (Kube-AWS), Amazon EKS e.t.c. In this guide, we will learn how to deploy a k0s Kubernetes Cluster on Rocky Linux 9 using k0sctl What is k0s? K0s is an open-source, simple, solid, and certified Kubernetes distribution that can be deployed on any infrastructure. It offers the simplest way with all the features required to set up a Kubernetes cluster. Due to its design and flexibility, it can be used on bare metal, cloud, Edge and IoT. K0s exists as a single binary with no dependencies aside from the host OS kernel required. This reduces the complexity and time involved when setting up a Kubernetes cluster. The other features associated with k0s are: It is certified and 100% upstream Kubernetes It has multiple installation methods such as single-node, multi-node, airgap and Docker. It offers automatic lifecycle management with k0sctl where you can upgrade, backup and restore. Flexible deployment options with control plane isolation as default It offers scalability from a single node to large, high-available clusters. Supports a variety of datastore backends. etcd is the default for multi-node clusters, SQLite for single node clusters, MySQL, and PostgreSQL can be used as well. Supports x86-64, ARM64 and ARMv7 It Includes Konnectivity service, CoreDNS and Metrics Server Minimum CPU requirements (1 vCPU, 1 GB RAM) k0sctl is a command-line tool used for bootstrapping and managing k0s clusters. Normally, it connects to the hosts using SSH and collects information about them. The information gathered is then used to create a cluster by configuring the hosts, deploying k0s, and then connecting them together. The below image can be used to demonstrate how k0sctl works Using k0sctl is the recommended way to create a k0s cluster for production. Since you can create multi-node clusters in an easy and automatic manner.

Now let’s dive in! Environment Setup For this guide, we will have the 4 Rocky Linux 9 servers configured as shown: Role Hostname IP Address Workspace workspace 192.168.204.12 Control plane master.computingpost.com 192.168.205.16 Worker Node worker1.computingpost.com 192.168.205.17 Worker Node worker2.computingpost.com 192.168.205.18 The other Rocky Linux 9 server is my working space on which I will install k0sctl and run the cluster on the above nodes Once the hostnames have been set, edit /etc/hosts on the Workspace as shown: $ sudo vi /etc/hosts 192.168.205.16 master.computingpost.com master 192.168.205.17 worker1.computingpost.com worker1 192.168.205.18 worker2.computingpost.com worker2 Since k0sctl uses SSH to access the hosts, we will generate SSH keys on the Workspace as shown: $ ssh-keygen Generating public/private rsa key pair. Enter file in which to save the key (/home/rocky9/.ssh/id_rsa): Enter passphrase (empty for no passphrase): Enter same passphrase again: Your identification has been saved in /home/rocky9/.ssh/id_rsa Your public key has been saved in /home/rocky9/.ssh/id_rsa.pub The key fingerprint is: SHA256:wk0LRhNDWM1PA2pm9RZ1EDFdx9ZXvhh4PB99mrJypeU rocky9@workspace The key's randomart image is: +---[RSA 3072]----+ | +B+o...*=.o*| | .. =o.o.oo..B| | B .ooo = o=| | * + o. . =o+| | o S ..=o | | . B | | . + E | | o | | | +----[SHA256]-----+ Ensure root login is permitted on the 3 nodes by editing /etc/ssh/sshd_config as below # Authentication: PermitRootLogin yes Save the file and restart the SSH service: sudo systemctl restart sshd Copy the keys to the 3 nodes. ssh-copy-id root@master ssh-copy-id root@worker1 ssh-copy-id root@worker2 Once copied, verify if you can log in to any of the nodes without a password: $ ssh root@worker1 Activate the web console with: systemctl enable --now cockpit.socket Last login: Sat Aug 20 11:38:29 2022 [root@worker1 ~]# exit Step 1 – Install the k0sctl tool on Rocky Linux 9 The k0sctl tool can be installed on the Rocky Linux 9 Workspace by downloading the file from the GitHub release page. You can also use wget to pull the archive. First, obtain the latest version tag: VER=$(curl -s https://api.github.com/repos/k0sproject/k0sctl/releases/latest|grep tag_name | cut -d '"' -f 4) echo $VER Now download the latest file for your system: ### For 64-bit ### wget https://github.com/k0sproject/k0sctl/releases/download/$VER/k0sctl-linux-x64 -O k0sctl ###For ARM ### wget https://github.com/k0sproject/k0sctl/releases/download/$VER/k0sctl-linux-arm -O k0sctl Once the file has been downloaded, make it executable and copy it to your PATH: chmod +x k0sctl sudo cp -r k0sctl /usr/local/bin/ /bin Verify the installation: $ k0sctl version version: v0.13.2 commit: 7116025 To enable shell completions, use the commands: ### Bash ### sudo sh -c 'k0sctl completion >/etc/bash_completion.d/k0sctl' ### Zsh ### sudo sh -c 'k0sctl completion > /usr/local/share/zsh/site-functions/_k0sctl' ### Fish ### k0sctl completion > ~/.config/fish/completions/k0sctl.fish Step 2 – Configure the k0s Kubernetes Cluster We will create a configuration file for the cluster. To generate the default configuration, we will use the command: k0sctl init > k0sctl.yaml Now modify the generated config file to work for your environment: vim k0sctl.yaml Update the config file as shown: apiVersion: k0sctl.k0sproject.io/v1beta1 kind: Cluster metadata: name: k0s-cluster spec: hosts: - ssh: address: master.computingpost.com user: root port: 22 keyPath: /home/$USER/.ssh/id_rsa role: controller - ssh: address: worker1.computingpost.com user: root port: 22 keyPath: /home/$USER/.ssh/id_rsa role: worker - ssh: address: worker2.computingpost.com

user: root port: 22 keyPath: /home/$USER/.ssh/id_rsa role: worker k0s: dynamicConfig: false We have a configuration file with 1 control plane and 2 worker nodes. It is also possible to have a single node deployment where you have a single server to act as a control plane and worker node as well: For that case, you will a configuration file appear as shown: apiVersion: k0sctl.k0sproject.io/v1beta1 kind: Cluster metadata: name: k0s-cluster spec: hosts: - ssh: address: IP_Address user: root port: 22 keyPath: /home/$USER/.ssh/id_rsa role: controller+worker k0s: dynamicConfig: false Step 3 – Create the k0s Kubernetes Cluster on Rocky Linux 9 using k0sctl Once the configuration has been made, you can start the cluster by applying the configuration file: First, allow the service through the firewall on the control plane sudo firewall-cmd --add-port=6443/tcp --permanent sudo firewall-cmd --reload Now apply the config k0sctl apply --config k0sctl.yaml Sample Output: ⠀⣿⣿⡇⠀⠀⢀⣴⣾⣿⠟⠁⢸⣿⣿⣿⣿⣿⣿⣿⡿⠛⠁⠀⢸⣿⣿⣿⣿⣿⣿⣿⣿⣿⣿⣿⠀█████████ █████████ ███ ⠀⣿⣿⡇⣠⣶⣿⡿⠋⠀⠀⠀⢸⣿⡇⠀⠀⠀⣠⠀⠀⢀⣠⡆⢸⣿⣿⠀⠀⠀⠀⠀⠀⠀⠀⠀⠀███ ███ ███ ⠀⣿⣿⣿⣿⣟⠋⠀⠀⠀⠀⠀⢸⣿⡇⠀⢰⣾⣿��⠀⣿⣿⡇⢸⣿⣿⣿⣿⣿⣿⣿⣿⣿⣿⣿⠀███ ███ ███ ⠀⣿⣿⡏⠻⣿⣷⣤⡀⠀⠀⠀⠸⠛⠁⠀⠸⠋⠁⠀⠀⣿⣿⡇⠈⠉⠉⠉⠉⠉⠉⠉⠉⢹⣿⣿⠀███ ███ ███ ⠀⣿⣿⡇⠀⠀⠙⢿⣿⣦⣀⠀⠀⠀⣠⣶⣶⣶⣶⣶⣶⣿⣿⡇⢰⣶⣶⣶⣶⣶⣶⣶⣶⣾⣿⣿⠀█████████ ███ ██████████ k0sctl v0.13.2 Copyright 2021, k0sctl authors. Anonymized telemetry of usage will be sent to the authors. By continuing to use k0sctl you agree to these terms: https://k0sproject.io/licenses/eula INFO ==> Running phase: Connect to hosts INFO [ssh] master:22: connected INFO [ssh] worker1:22: connected INFO [ssh] worker2:22: connected INFO ==> Running phase: Detect host operating systems INFO [ssh] master:22: is running Rocky Linux 9.0 (Blue Onyx) INFO [ssh] worker1:22: is running Rocky Linux 9.0 (Blue Onyx) INFO [ssh] worker2:22: is running Rocky Linux 9.0 (Blue Onyx) INFO ==> Running phase: Acquire exclusive host lock INFO ==> Running phase: Prepare hosts INFO ==> Running phase: Gather host facts ......... INFO [ssh] worker2:22: validating api connection to https://192.168.205.16:6443 INFO [ssh] master:22: generating token INFO [ssh] worker1:22: writing join token INFO [ssh] worker2:22: writing join token INFO [ssh] worker1:22: installing k0s worker INFO [ssh] worker2:22: installing k0s worker INFO [ssh] worker1:22: starting service INFO [ssh] worker2:22: starting service INFO [ssh] worker1:22: waiting for node to become ready INFO [ssh] worker2:22: waiting for node to become ready Once complete, you will see this: Install kubectl You may need to install kubectl on the workspace to help you manage the cluster with ease. Download the binary file and install it with the command: curl -LO "https://storage.googleapis.com/kubernetes-release/release/$(curl -s https://storage.googleapis.com/kubernetes-release/release/stable.txt)/bin/linux/amd64/kubectl" chmod +x kubectl sudo mv kubectl /usr/local/bin/ /bin Verify the installation: $ kubectl version --client Client Version: version.InfoMajor:"1", Minor:"24", GitVersion:"v1.24.4", GitCommit:"95ee5ab382d64cfe6c28967f36b53970b8374491", GitTreeState:"clean", BuildDate:"2022-08-17T18:54:23Z", GoVersion:"go1.18.5", Compiler:"gc", Platform:"linux/amd64" Kustomize Version: v4.5.4 To be able to access the cluster with kubectl, you need to get the kubeconfig file and set the environment. k0sctl kubeconfig > kubeconfig export KUBECONFIG=$PWD/kubeconfig Now get the nodes in the cluster: $ kubectl get nodes NAME STATUS ROLES AGE VERSION worker1.computingpost.com Ready 7m59s v1.24.3+k0s worker2.computingpost.com Ready 7m59s v1.24.3+k0s The above command will only list the worker nodes. This is because K0s ensures that the controllers and workers are isolated.

Get all the pods running: $ kubectl get pods --all-namespaces NAMESPACE NAME READY STATUS RESTARTS AGE kube-system coredns-88b745646-djcjh 1/1 Running 0 11m kube-system coredns-88b745646-v9vfn 1/1 Running 0 9m34s kube-system konnectivity-agent-8bm85 1/1 Running 0 9m36s kube-system konnectivity-agent-tsllr 1/1 Running 0 9m37s kube-system kube-proxy-cdvjv 1/1 Running 0 9m37s kube-system kube-proxy-n6ncx 1/1 Running 0 9m37s kube-system kube-router-fhm65 1/1 Running 0 9m37s kube-system kube-router-v5srj 1/1 Running 0 9m36s kube-system metrics-server-7d7c4887f4-gv94g 0/1 Running 0 10m Step 4 – Advanced K0sctl File Configurations Once a cluster has been deployed, the default configuration file for the cluster is created. To view the file, access the file, use the command below on the control plane: # k0s default-config > /etc/k0s/k0s.yaml The file looks as shown: # cat /etc/k0s/k0s.yaml # generated-by-k0sctl 2022-08-20T11:57:29+02:00 apiVersion: k0s.k0sproject.io/v1beta1 kind: ClusterConfig metadata: creationTimestamp: null name: k0s spec: api: address: 192.168.205.16 k0sApiPort: 9443 port: 6443 sans: - 192.168.205.16 - fe80::e4f8:8ff:fede:e1a5 - master - 127.0.0.1 tunneledNetworkingMode: false controllerManager: extensions: helm: charts: null repositories: null storage: create_default_storage_class: false type: external_storage images: calico: cni: image: docker.io/calico/cni version: v3.23.3 kubecontrollers: image: docker.io/calico/kube-controllers version: v3.23.3 node: image: docker.io/calico/node version: v3.23.3 coredns: image: k8s.gcr.io/coredns/coredns version: v1.7.0 default_pull_policy: IfNotPresent konnectivity: image: quay.io/k0sproject/apiserver-network-proxy-agent version: 0.0.32-k0s1 kubeproxy: image: k8s.gcr.io/kube-proxy version: v1.24.3 kuberouter: cni: image: docker.io/cloudnativelabs/kube-router version: v1.4.0 cniInstaller: image: quay.io/k0sproject/cni-node version: 1.1.1-k0s.0 metricsserver: image: k8s.gcr.io/metrics-server/metrics-server version: v0.5.2 pushgateway: image: quay.io/k0sproject/pushgateway-ttl version: edge@sha256:7031f6bf6c957e2fdb496161fe3bea0a5bde3de800deeba7b2155187196ecbd9 installConfig: users: etcdUser: etcd kineUser: kube-apiserver konnectivityUser: konnectivity-server kubeAPIserverUser: kube-apiserver kubeSchedulerUser: kube-scheduler konnectivity: adminPort: 8133 agentPort: 8132 network: calico: null clusterDomain: cluster.local dualStack: kubeProxy: mode: iptables kuberouter: autoMTU: true mtu: 0 peerRouterASNs: "" peerRouterIPs: "" podCIDR: 10.244.0.0/16 provider: kuberouter serviceCIDR: 10.96.0.0/12 podSecurityPolicy: defaultPolicy: 00-k0s-privileged scheduler: storage: etcd: externalCluster: null peerAddress: 192.168.205.16 type: etcd telemetry: enabled: true status: You can modify the file as desired and then apply the changes made with the command: sudo k0s install controller -c The file can be modified if the cluster is running. But for the changes to apply, restart the cluster with the command: sudo k0s stop sudo k0s start Configure Cloud Providers The K0s-managed Kubernetes doesn’t include the built-in cloud provider service. You need to manually configure and add its support. There are two ways of doing this:

Using K0s Cloud Provider K0s provides its own lightweight cloud provider that can be used to assign static external IP to expose the worker nodes. This can be done using either of the commands: #worker sudo k0s worker --enable-cloud-provider=true #controller sudo k0s controller --enable-k0s-cloud-provider=true After this, you can add the IPv4 and IPv6 static node IPs: kubectl annonate node k0sproject.io/node-ip-external= Using Built-in Cloud Manifest Manifests allow one to run the cluster with preferred extensions. Normally, the controller reads the manifests from /var/lib/k0s/manifests This can be verified from the control node: $ ls -l /var/lib/k0s/ total 12 drwxr-xr-x. 2 root root 120 Aug 20 11:57 bin drwx------. 3 etcd root 20 Aug 20 11:57 etcd -rw-r--r--. 1 root root 241 Aug 20 11:57 konnectivity.conf drwxr-xr-x. 15 root root 4096 Aug 20 11:57 manifests drwxr-x--x. 3 root root 4096 Aug 20 11:57 pki With this option, you need to create a manifest with the below syntax: --- apiVersion: v1 kind: ServiceAccount metadata: name: cloud-controller-manager namespace: kube-system --- apiVersion: rbac.authorization.k8s.io/v1 kind: ClusterRoleBinding metadata: name: system:cloud-controller-manager roleRef: apiGroup: rbac.authorization.k8s.io kind: ClusterRole name: cluster-admin subjects: - kind: ServiceAccount name: cloud-controller-manager namespace: kube-system --- apiVersion: apps/v1 kind: DaemonSet metadata: labels: k8s-app: cloud-controller-manager name: cloud-controller-manager namespace: kube-system spec: selector: matchLabels: k8s-app: cloud-controller-manager template: metadata: labels: k8s-app: cloud-controller-manager spec: serviceAccountName: cloud-controller-manager containers: - name: cloud-controller-manager # for in-tree providers we use k8s.gcr.io/cloud-controller-manager # this can be replaced with any other image for out-of-tree providers image: k8s.gcr.io/cloud-controller-manager:v1.8.0 command: - /usr/local/bin/cloud-controller-manager - --cloud-provider=[YOUR_CLOUD_PROVIDER] # Add your own cloud provider here! - --leader-elect=true - --use-service-account-credentials # these flags will vary for every cloud provider - --allocate-node-cidrs=true - --configure-cloud-routes=true - --cluster-cidr=172.17.0.0/16 tolerations: # this is required so CCM can bootstrap itself - key: node.cloudprovider.kubernetes.io/uninitialized value: "true" effect: NoSchedule # this is to have the daemonset runnable on master nodes # the taint may vary depending on your cluster setup - key: node-role.kubernetes.io/master effect: NoSchedule # this is to restrict CCM to only run on master nodes # the node selector may vary depending on your cluster setup nodeSelector: node-role.kubernetes.io/master: "" Step 5 – Deploy an Application on k0s To test if the cluster is working as desired, we will create a deployment for the Nginx application: The command below can be used to create and apply the manifest: kubectl apply -f -

0 notes

leanesch · 2 years ago

Text

Kubernetes must know:

First thing to know is that Kubernetes has many competitors such as Docker Swarm, Zookeeper, Nomad etc.. and Kubernetes is not the solution for every architecture so please define your requirements and check other alternatives first before starting with Kuberenetes as it can be complex or not really that beneficial in your case and that an easier orchestrator can do the job.

If you are using a cloud provider, and you want a managed kubernetes service, you can check EKS for AWS, GCP for Google Cloud or AKS for Azure.

Make sure to have proper monitoring and alerting for your cluster as this enables more visibility and eases the management of containerized infrastructure by tracking utilization of cluster resources including memory, CPU, storage and networking performance. It is also recommended to monitor pods and applications in the cluster. The most common tools used for Kubernetes monitoring are ELK/EFK, datadog, Prometheus and Grafana which will be my topic for the next article, etc..

Please make sure to backup your cluster’s etcd data regularly.

In order to ensure that your kubernetes cluster resources are only accessed by certain people, it's recommended to use RBAC in your cluster in order to build roles with the right access.

Scalability and what's more important than scalability, 3 types we must know and include in our cluster architecture are Cluster autoscaler, HPA and VPA.

Resource management is important as well, setting and rightsizing cluster resources requests and limits will help avoiding issues like OOM and Pod eviction and saves you money!

You may want to check Kubernetes CIS Benchmark which is a set of recommendations for configuring Kubernetes to support a strong security posture, you can take a look at this article to learn more about it.

Try to always get the latest Kubernetes stable GA version for newer functionalities and if using cloud, for supported versions.

Scan containers for security vulnerabilities is very important as well, here we can talk about tools like Kube Hunter, Kube Bench etc..

Make use of Admission controllers when possible as they intercept and process requests to the Kubernetes API prior to persistence of the object, but after the request is authenticated and authorized, which is used when you have a set of constraints/behavior to be checked before a resource is deployed. It can also block vulnerable images from being deployed.

Speaking about Admission controller, you can also enforce policies in Kubernetes using a tool like OPA which lets you define sets of security and compliance policies as code.

Using a tool like Falco for auditing the cluster, this is a nice way to log and monitor real time activities and interactions with the API.

Another thing to take a look at is how to handle logging of applications running in containers (I recommend checking logging agents such fluentd/fluentbit) and especially how to setup Log rotation to reduce the storage growth and avoid performance issues.

In case you have multiple microservices running in the cluster, you can also implement a service mesh solution in order to have a reliable and secure architecture and other features such as encryption, authentication, authorization, routing between services and versions and load balancing. One of the famous service mesh solutions is Istio. You can take a look at this article for more details about service mesh.

One of the most important production ready clusters features is to have a backup&restore solution and especially a solution to take snapshots of your cluster’s Persistent Volumes. There are multiple tools to do this that you might check and benchmark like velero, portworx etc..

You can use quotas and limit ranges to control the amount of resources in a namespace for multi-tenancy.

For multi cluster management, you can check Rancher, weave Flux, Lens etc..

#kubernetes #technology #IT #devops #programmer #software developers #security #privacy

0 notes

for-the-user · 6 years ago

Text

heptio ark k8s cluster backups

How do we use it? (in this example, i am using microsoft azure's cloud)

Prepare some cloud storage

Create a storage account and a blob container in the same subscription and resource group as the k8s cluster you want to be running backups on.

$ az storage account create \ --name $AZURE_STORAGE_ACCOUNT_ID \ --resource-group $RESOURCE_GROUP \ --sku Standard_LRS \ --encryption-services blob \ --https-only true \ --kind BlobStorage \ --access-tier Cool \ --subscription $SUBSCRIPTION $ az storage container create \ -n $STORAGE_RESOURCE_NAME \ --public-access off \ --account-name $AZURE_STORAGE_ACCOUNT_ID \ --subscription $SUBSCRIPTION

Get the storage account access key.

$ AZURE_STORAGE_KEY=`az storage account keys list \ --account-name $AZURE_STORAGE_ACCOUNT_ID \ --resource-group $RESOURCE_GROUP \ --query '[0].value' \ --subscription $SUBSCRIPTION \ -o tsv`

Create a service principle with appropriate permissions for heptio ark to use to read and write to the storage account.

$ az ad sp create-for-rbac \ --name "heptio-ark" \ --role "Contributor" \ --password $AZURE_CLIENT_SECRET \ --subscription $SUBSCRIPTION

Finally get the service principle's id called a client id.

$ AZURE_CLIENT_ID=`az ad sp list \ --display-name "heptio-ark" \ --query '[0].appId' \ --subscription $SUBSCRIPTION \ -o tsv`

Provision ark

Next we provision an ark instance to our kubernetes cluster with a custom namespace. First clone the ark repo

$ git clone https://github.com/heptio/ark.git

You will need to edit 3 files.

ark/examples/common/00-prereqs.yaml ark/examples/azure/00-ark-deployment.yaml ark/examples/azure/10.ark-config.yaml

In these yamls, it tries to create a namespace called "heptio-ark" and then put things into that namespace. Change all of these references to a namespace you prefer. I called it "my-groovy-system".

In the 10.ark-config.yaml, you also need to replace the placeholders YOUR_TIMEOUT & YOUR_BUCKET with some actual values. in our case, we use: 15m and the value of $STORAGE_RESOURCE_NAME, which in this case is ark-backups.

Create the pre-requisites.

$ kubectl apply -f examples/common/00-prereqs.yaml customresourcedefinition "backups.ark.heptio.com" created customresourcedefinition "schedules.ark.heptio.com" created customresourcedefinition "restores.ark.heptio.com" created customresourcedefinition "configs.ark.heptio.com" created customresourcedefinition "downloadrequests.ark.heptio.com" created customresourcedefinition "deletebackuprequests.ark.heptio.com" created customresourcedefinition "podvolumebackups.ark.heptio.com" created customresourcedefinition "podvolumerestores.ark.heptio.com" created customresourcedefinition "resticrepositories.ark.heptio.com" created namespace "my-groovy-system" created serviceaccount "ark" created clusterrolebinding "ark" created

Create a secret object, which contains all of the azure ids we gathered in part 1.

$ kubectl create secret generic cloud-credentials \ --namespace my-groovy-system \ --from-literal AZURE_SUBSCRIPTION_ID=$SUBSCRIPTION \ --from-literal AZURE_TENANT_ID=$TENANT_ID \ --from-literal AZURE_RESOURCE_GROUP=$RESOURCE_GROUP \ --from-literal AZURE_CLIENT_ID=$AZURE_CLIENT_ID \ --from-literal AZURE_CLIENT_SECRET=$AZURE_CLIENT_SECRET \ --from-literal AZURE_STORAGE_ACCOUNT_ID=$AZURE_STORAGE_ACCOUNT_ID \ --from-literal AZURE_STORAGE_KEY=$AZURE_STORAGE_KEY secret "cloud-credentials" created

Provision everything.

$ kubectl apply -f examples/azure/ $ kubectl get deployments -n my-groovy-system NAME DESIRED CURRENT UP-TO-DATE AVAILABLE AGE ark 1 1 1 1 1h $ kubectl get pods -n my-groovy-system NAME READY STATUS RESTARTS AGE ark-7b86b4d5bd-2w5x7 1/1 Running 0 1h $ kubectl get rs -n my-groovy-system NAME DESIRED CURRENT READY AGE ark-7b86b4d5bd 1 1 1 1h $ kubectl get secrets -n my-groovy-system NAME TYPE DATA AGE ark-token-b5nm8 kubernetes.io/service-account-token 3 1h cloud-credentials Opaque 7 1h default-token-xg6x4 kubernetes.io/service-account-token 3 1h

At this point the ark server is running. To interact with it, we need to use a client.

Install the Ark client locally

Download one from here and unzip it and add it to your path. Here's a mac example:

$ wget https://github.com/heptio/ark/releases/download/v0.9.3/ark-v0.9.3-darwin-amd64.tar.gz $ tar -xzvf ark-v0.9.3-darwin-amd64.tar.gz $ mv ark /Users/mygroovyuser/bin/ark $ ark --help

Take this baby for a test drive

Deploy an example thing. Ark provides something to try with.

$ kubectl apply -f examples/nginx-app/base.yaml

This creates a namespace called nginx-example and creates a deployment and service inside with a couple of nginx pods.

Take a backup.

$ ark backup create nginx-backup --include-namespaces nginx-example --namespace my-groovy-system Backup request "nginx-backup" submitted successfully. Run `ark backup describe nginx-backup` for more details. $ ark backup get nginx-backup --namespace my-groovy-system NAME STATUS CREATED EXPIRES SELECTOR nginx-backup Completed 2018-08-21 15:57:59 +0200 CEST 29d

We can see in our Azure storage account container a backup has been created by heptio ark.

If we look inside the folder, we see some json and some gzipped stuff

Let's simulate a disaster.

$ kubectl delete namespace nginx-example namespace "nginx-example" deleted

And try to restore from the Ark backup.

$ ark restore create --from-backup nginx-backup --namespace my-groovy-system Restore request "nginx-backup-20180821160537" submitted successfully. Run `ark restore describe nginx-backup-20180821160537` for more details. $ ark restore get --namespace my-groovy-system NAME BACKUP STATUS WARNINGS ERRORS CREATED SELECTOR nginx-backup-20180821160537 nginx-backup Completed 0 0 2018-08-21 16:05:38 +0200 CEST

Nice.

And to delete backups...

$ ark backup delete nginx-backup --namespace my-groovy-system Are you sure you want to continue (Y/N)? Y Request to delete backup "nginx-backup" submitted successfully. The backup will be fully deleted after all associated data (disk snapshots, backup files, restores) are removed. $ ark backup get nginx-backup --namespace my-groovy-system An error occurred: backups.ark.heptio.com "nginx-backup" not found

And its gone.

#k8s #kubernetes #heptio #ark #backups

2 notes · View notes

digital-dynasty · 4 years ago

Text

Cloud-native: Kubermatic Kubernetes Platform 2.17 bietet automatisierte Backups

Kubermatic nutzt ein neues Meta-Plug-in für Container Networking Interfaces und neue etcd-Controller erlauben automatische Datensicherung sowie Restores. Read more www.heise.de/news/…... www.digital-dynasty.net/de/teamblogs/…

http://www.digital-dynasty.net/de/teamblogs/cloud-native-kubermatic-kubernetes-platform-2-17-bietet-automatisierte-backups

0 notes
