#Actuator

[radfestivaldreamer]

Johnson Controls VA9104-AGA-3S Electric Ball Valve NSR Floating 2-Position Actuator 24V 35 LB-IN | PartsHnC

The Johnson Controls VA9104-AGA-3S Electric Ball Valve Actuator is a small and dependable option for managing water flow in HVAC systems, especially those with limited space. This lightweight item (1.25 lbs) is made of high-strength thermoplastic for durability and has a direct-mount design for simple installation on the ball valve.

[ampselectric]

[hvacparts02]

Schneider Electric AP33A000 Non Spring Return 24V Proportional Actuator_PartsHnC

The Schneider Electric (Erie) AP33A000 is a cutting-edge 24V non-spring return actuator that will transform HVAC system control. It provides accurate modulation for valves, dampers, and other HVAC equipment when using a 0–10V DC or 4��20mA control signal.

[fantasticzombiefire]

Johnson Controls V-3801-8001 Pneumatic Compact Oval Actuator | PartsHnC

The Johnson Controls V-3801-8001 Pneumatic Compact Oval Actuator is a versatile component used in HVAC systems to control dampers and valves. This actuator uses pneumatic power to control and alter fluid and airflow within a pressure range of 3 to 15 PSI. In order to ensure optimal system performance, it opens or closes valves and dampers by translating pneumatic impulses into mechanical action.

[digilogic-system]

Digilogic's Actuator Test Systems

Digilogic's Actuator Test System uses advanced equipment including a Frequency Response Analyzer, Universal Waveform Generator, Data Acquisition System, Servo Control Unit, and Load cell test setup.

The Actuator Test System is used to measure the performance of the Actuator using the Sine, Step, and Triangle waveform generated by the Universal Waveform Generator. Utilizing PXIe modules with LabVIEW software, the Actuator test system conducts comprehensive tests on Actuators. Data acquired from the testing process can be stored securely and analyzed to effectively meet the user's needs.

Digilogic's Actuator Test System, tailored for the demanding requirements of the defense and aerospace sectors, offers a comprehensive solution for testing actuators. The system employs an integrated approach, combining static and dynamic testing methodologies to rigorously evaluate the reliability and performance of actuators destined for mission-critical applications.

For more information about Digilogic's Actuator Test System, click the link below. https://bit.ly/3UuQSon

For any queries (or) to request a quote, Contact us. Phone: Hyderabad: (+91) 40 4547 4601 Bengaluru: (+91) 80 4975 6034 Website: www.digilogicsystems.com Email: info@digilogicsystems.com

Please stay connected with us on our other social media channels for the latest updates! YouTube: https://www.youtube.com/@digilogicsystems LinkedIn: https://www.linkedin.com/company/digilogicsystems/ Instagram: https://www.instagram.com/digilogic_systems/ Twitter: https://twitter.com/DigilogicSystem

[hvacparts09]

Siemens S55180-A151 Powermite MZ Series Actuator Non-Spring Return |PartsHnC

Manufacturer Name: Siemens Building Technology Product Number: S55180-A151 OEM Part Number: S55180-A151

The Siemens S55180-A151 Powermite MZ Series Actuator is a non-spring return actuator designed for precise control of HVAC systems. Operating at 24V AC/DC, this actuator utilizes a 0-10 VDC control signal to modulate valves and dampers, providing accurate adjustments in response to varying system demands.

[partshnc03]

Taco Za024Q4A2-24V 2W/3W N/C Actuator | PartsHnC

Manufacturer Name: Taco Product Number: ZA024Q4A2 OEM Part Number: ZA024Q4A2

The Taco ZA024Q4A2 24V 2W/3W N/C Actuator is an important component in HVAC systems, regulating fluid or gas flow for heating and cooling. It operates on a 24-volt power supply and has a default closed mechanism that only opens when activated.

https://www.partshnc.com/za024q4a2-taco-24v-2w3w-nc-actuator

[anbi-group]

HERZ Actuator For Two Way Control Valve 17712

[electronic-component]

What is an Actuator? A Comprehensive Overview

1. What is an Actuator?

An actuator is a device that converts energy into mechanical motion, playing a crucial role in various systems and applications where motion is needed. Actuators are essential components in automation, robotics, vehicles, industrial machinery, and many other fields. They are responsible for moving or controlling a mechanism or system, making them vital in bridging the gap between digital commands and physical movements. Essentially, an actuator can take input energy in various forms—electrical, hydraulic, pneumatic, or mechanical—and transform it into linear or rotational motion. This transformation is fundamental in applications that require precise control of movements.

2. Types of Actuators

Actuators come in several types, each suited to different applications depending on the source of energy and desired motion. The three primary types are electric, pneumatic, and hydraulic actuators. Electric actuators use electrical energy to produce motion and are commonly used in robotics, home automation, and precision instruments due to their accuracy and control. Pneumatic actuators use compressed air to generate motion and are often used in industrial automation for applications requiring rapid movements and simple control. Hydraulic actuators, on the other hand, utilize pressurized fluids to produce large forces and are ideal for heavy-duty applications such as construction equipment and aircraft control systems.

3. Working Principle of Actuators

The operation of an actuator depends on its type and the energy source it uses. For instance, in an electric actuator, an electric motor drives a mechanism—such as a screw, gear, or belt—that converts electrical energy into mechanical motion. Pneumatic actuators work by converting the energy of compressed air into mechanical force, often using pistons or diaphragms to create movement. Hydraulic actuators function similarly but use hydraulic fluid instead of air. Each type of actuator involves converting one form of energy into another, resulting in linear or rotary motion. The specific mechanics and design of an actuator influence its performance characteristics, such as speed, force, and precision.

4. Applications of Actuators

Actuators are ubiquitous in modern technology, finding applications across numerous industries and systems. In industrial automation, they play a crucial role in manufacturing processes, moving parts and materials with high precision and reliability. In robotics, actuators are vital for controlling the movement of robotic arms, legs, and other components, enabling robots to perform complex tasks in fields such as healthcare, warehousing, and autonomous vehicles. They are also essential in automotive systems, where they control various functions like power windows, braking systems, and engine control mechanisms. In smart homes, actuators are found in automated doors, HVAC systems, and lighting, adding comfort and energy efficiency.

5. Future Trends and Developments in Actuators

The future of actuators is evolving with advancements in materials science, control systems, and digital technologies. Innovations such as piezoelectric and shape-memory actuators are gaining attention due to their compact size, efficiency, and precision. There is also a growing trend towards integrating smart actuators that combine sensing, control, and actuation into a single unit, providing enhanced capabilities for IoT (Internet of Things) and smart manufacturing. Developments in artificial intelligence and machine learning are also influencing actuator technology, enabling adaptive and predictive control for complex and dynamic environments. These advancements point to a future where actuators are more responsive, intelligent, and versatile, supporting the next generation of automation and robotics systems.

[radfestivaldreamer]

Johnson Controls VA9203-BGA-2 Electric Valve Spring Return Actuator On/Off 2-Position 24V 75 Second | PartsHnC

The Johnson Controls VA9203-BGA-2 is an electronic valve actuator designed to automate ball valves in HVAC systems, namely zone control and air handling units. This compact and lightweight (2.71 lbs) machine has a spring-return mechanism. When powered by 24V AC power, the motor moves the valve to a specific on or off state (2-position control) within 75 seconds.

[hvacparts02]

Honeywell M7410F1000 Actuator 0/2-10 VDC for 1/2 & 3/4 Inch V58XX | PartsHnC

The Honeywell M7410F1000 actuator is meant for variable air volume VAV terminal units in HVAC systems. It operates by turning a 0–10Vdc or 2–10Vdc control signal into accurate positioning of butterfly valves, which typically come in sizes of 1/2 and 3/4.

[fantasticzombiefire]

Siemens S55155-A110 Non-Spring Return Valve Actuator 24VAC 0-10VDC | PartsHnC

The Siemens S55155-A110 Non-Spring Return Valve Actuator is a small and efficient actuator for precision HVAC system management. This actuator, which runs on a 24VAC/DC power source, is designed to deliver dependable performance in a range of HVAC applications. Its 0–10VDC control signal enables smooth valve position modulation, guaranteeing ideal flow control and energy efficiency in HVAC equipment such fan coil units, chilled water systems, and air handling units.

[controlsystemsandsemiconductor]

Product - M9109-GGA-4

Description - Johnson controls M9109-GGA-4 24V AC/DC Proportional Electric Actuator Module.

Buying Link - https://controlss.net/products/automation-parts/m9109-gga-4/

[hvacparts09]

Honeywell MN6105A1011 Non-Spring Return Actuator Floating 2-Position|PartsHnC

Manufacturer Name: Honeywell Product Number: MN6105A1011 OEM Part Number: MN6105A1011

The Honeywell MN6105A1011 is a precision-engineered floating/2-position actuator intended for 24V AC/DC use. With its exact functionality, this advanced device provides dependable performance in regulating a variety of systems.

[partshnc03]

Belimo Lmb24-Sr-T-24V;45#;2-10Vdcprop;W/Termnals | PartsHnC

Manufacturer Name: Belimo Product Number: LMB24-SR-T OEM Part Number: LMB24-SR-T

The Belimo LMB24-SR-T is a 24V, 45 in-lb (5 Nm) actuator designed for modulating control of dampers and air handling units. It features a 2-10V DC proportional control signal, providing precise positioning for HVAC systems.

https://www.partshnc.com/24v452-10vdcpropwtermnals-3
