SITE PLAN

LINK - DWG Site Plan Lincoln Road

[fiu-soa-d1-g1]

A few more examples from previous years. These are at 1/8" scale so a bit later in the progress....You are working at 1/16" for Monday, so yours will be more "sketchy". The FIELD is important

[fiu-soa-d1-g1]

A few plan / section examples from prior semesters. Notice the relationship of the plan to the section...Also see how the ground has been manipulated over the entire site. Think of the project as a "field" rather than an object.

[fiu-soa-d1-g1]

Site Visit

Wednesday 16 OCT > 2:30p

The colored plan should be at 1/16" scale when printed on 11x17

[fiu-soa-d1-g1]

[fiu-soa-d1-g1]

[fiu-soa-d1-g1]

[fiu-soa-d1-g1]

WEEK 4

Monday 23 SEP

DUE revised sketch (study) model

chipboard and museum board

one hand-drawn plan (grid paper 11x17) actual size

one hand-drawn section (grid paper 11x17) actual size

5p Lecture Geometry / Sketching

5p Intro EX3 (Section / Plan Square CAD)

Wednesday 25 SEP

DUE Reading (Ch 1 + Ch 22)

Studio work

5p Lecture Axonometric + Walker House

5p Intro EX4 (Simple Axo)

Thursday 26 SEP

DUE PLAN 2 (Walker Guest House)

12:30p Nedev mtg > Section U04 (Kedan)

[fiu-soa-d1-g1]

WEEK 1

MON 26 AUG

Frist day Intro / Desks

WED 28 AUG

working session on 11 x 17 Courtyard

materials from Blick

THU 29 AUG

DUE list of Small Pleasures

DUE Zumthor/Calvino readings

DUE finished DRAFT of courtyard drawing (started yesterday)

INTRO EX1 (Initials) – it’s on the Tumblr

by next Monday they should have AutoCAD installed

by next Monday should have supplies from Blick

for Wednesday revised 11x17 courtyard drawing

check out AutoCAD YouTube lecture (Tumblr)

WEEK 2

MON 02 SEP

Labor Day (No Class)

TUE 03 SEP

Last day for students to Drop / Add course (FYI)

WED 04 SEP

DUE revised 11x17 courtyard PLAN (1/10" scale)

INTRO P1.2 (1/8” scale) Courtyard (I will provide copies)

5p Lecture Projection & Farnsworth house in Auditorium (NN)

Intro EX2 Simple Projection

THU 05 SEP

12:30p NN informal meeting with section U01

DUE EX 1 (Initials) PRINTED 8.5 x 11

[fiu-soa-d1-g1]

Brief Tutorial on the AutoCAD Basics

- general lineweights (plan examples)

- open new file

- template (CTB not STB)

- interface (classic vs new)

- right click customization

- units

- scale of drawing (actual size)

- sheets

- general commands (from EX 1)

- CTB file (on MAC import)

- print

LAYERS

- thickness vs per element

[fiu-soa-d1-g1]

DUE PRINTED NEXT THURSDAY (SEP 5)

[fiu-soa-d1-g1]

At 1:15 you will see the laser robots that scan the space ship and make a 3D model of the cavern
