arch497-08 · 9 years ago
Video
youtube
0 notes
arch497-08 · 9 years ago
Tumblr media
0 notes
arch497-08 · 10 years ago
Tumblr media Tumblr media Tumblr media Tumblr media Tumblr media Tumblr media
Flash Detector with Analog Interrupt Code
int flashes = 0;
int wait = 1000;
void setup()
{
  pinMode(7,INPUT);
  pinMode(13, OUTPUT);
  Serial.begin(9600);
  ACSR = B01011010; // comparator interrupt enabled and tripped on falling edge.
  digitalWrite(13, HIGH);
}
void loop()
{
  for(int i=0; i<flashes; i++)
  {
    digitalWrite(13, LOW);
    delay(100);
    digitalWrite(13, HIGH);
    delay(100);
  }
  delay(1000);
}
ISR(ANALOG_COMP_vect)
{
  flashes++;
  Serial.print("Number of Flashes: ");
  Serial.println(flashes);
  delay(wait);
}
0 notes
arch497-08 · 10 years ago
Video
tumblr
Camera Flash around Crown Hall
0 notes
arch497-08 · 10 years ago
Video
tumblr
The more a door is used the brighter its leds become.
Code:
int wdPin=13;
int edPin=12;
int wHall=0;
int eHall=0;
int westLight=3;
int eastLight=5;
int westCount=0;
int eastCount=0;
int totalCount=0;
int westValue=0;
int eastValue=0;
String wdState=”closed”;
String edState=”closed”;
int maxValue=255;
void setup()
{
  pinMode(wdPin, INPUT);
  pinMode(edPin, INPUT);
  pinMode(eastLight, INPUT);
  pinMode(westLight, INPUT);
  Serial.begin(9600);
}
void loop()
{
    processWest();
    processEast();
    processCount();
    processOutput();
    delay(1000);
}
void processWest()
  {
   wHall = digitalRead(wdPin);
  // Serial.println(wHall);
   if (wdState.equals(“closed”))
   {
       if(wHall == HIGH)
       {
           westCount+=40;
           wdState=”open”;
       }
   }
   else
   {
     if(wHall==LOW)
     {
       wdState=”closed”;
     }
   }
  }
  void processEast()
  {
   eHall = digitalRead(edPin);
    Serial.println(eHall);
    if (edState.equals(“closed”))
   {
         if(eHall == HIGH)
         {
           eastCount+=40;
           edState=”open”;
         }
    }
    else
    {
     if(eHall==LOW)
     {
      edState=”closed”;
     }
   }
       }
  void processCount()
  {
    totalCount=eastCount+westCount;
    float eastPerc=(float)eastCount/(float)totalCount;
    Serial.println(eastPerc);
    float westPerc=(float)westCount/(float)totalCount;
    Serial.println(westPerc);
    if(eastCount>0)
    {
      eastValue=maxValue*eastPerc;
    }
    if(westCount>0)
    {
      westValue=maxValue*westPerc;
    }
  }
  void processOutput()
  {
    //int westValue = map(westValue, 0, maxValue, 0, 100);
    //int eastValue = map(eastValue, 0, maxValue, 0, 100);
    analogWrite(westLight,westValue);
    analogWrite(eastLight,eastValue);
    Serial.print(“West Value: “);
    Serial.println(westValue);
    Serial.print(“West Count: “);
    Serial.println(westCount);
    Serial.print(“East Value: “);
    Serial.println(eastValue);
    Serial.print(“East Count: “);
    Serial.println(eastCount);
    Serial.print(“Total Count: “);
    Serial.println(totalCount);
  }
2 notes · View notes
arch497-08 · 10 years ago
Tumblr media Tumblr media Tumblr media Tumblr media Tumblr media Tumblr media Tumblr media Tumblr media Tumblr media
1 note · View note
arch497-08 · 10 years ago
Video
tumblr
As one enters through a door the opposite door glows brighter to attract people and even out usage of both doors (symmetrical usage).
CODE:
int wdPin=13;
int edPin=12;
int wHall=0;
int eHall=0;
int westLight=3;
int eastLight=5;
int westCount=0;
int eastCount=0;
int totalCount=0;
int westValue=0;
int eastValue=0;
String wdState=”closed”;
String edState=”closed”;
int maxValue=255;
void setup()
{
  pinMode(wdPin, INPUT);
  pinMode(edPin, INPUT);
  pinMode(eastLight, INPUT);
  pinMode(westLight, INPUT);
  Serial.begin(9600);
}
void loop()
{
    processWest();
    processEast();
    processCount();
    processOutput();
    delay(1000);
}
void processWest()
  {
   wHall = digitalRead(wdPin);
  // Serial.println(wHall);
   if (wdState.equals(“closed”))
   {
       if(wHall == HIGH)
       {
           eastCount+=40;
           wdState=”open”;
       }
   }
   else
   {
     if(wHall==LOW)
     {
       wdState=”closed”;
     }
   }
  }
  void processEast()
  {
   eHall = digitalRead(edPin);
    Serial.println(eHall);
    if (edState.equals(“closed”))
   {
         if(eHall == HIGH)
         {
           westCount+=40;
           edState=”open”;
         }
    }
    else
    {
     if(eHall==LOW)
     {
      edState=”closed”;
     }
   }
       }
  void processCount()
  {
    totalCount=eastCount+westCount;
    float eastPerc=(float)eastCount/(float)totalCount;
    Serial.println(eastPerc);
    float westPerc=(float)westCount/(float)totalCount;
    Serial.println(westPerc);
    if(eastCount>0)
    {
      eastValue=maxValue*eastPerc;
    }
    if(westCount>0)
    {
      westValue=maxValue*westPerc;
    }
  }
  void processOutput()
  {
    //int westValue = map(westValue, 0, maxValue, 0, 100);
    //int eastValue = map(eastValue, 0, maxValue, 0, 100);
    analogWrite(westLight,westValue);
    analogWrite(eastLight,eastValue);
    Serial.print(“West Value: “);
    Serial.println(westValue);
    Serial.print(“West Count: “);
    Serial.println(westCount);
    Serial.print(“East Value: “);
    Serial.println(eastValue);
    Serial.print(“East Count: “);
    Serial.println(eastCount);
    Serial.print(“Total Count: “);
    Serial.println(totalCount
    );
  }
1 note · View note
arch497-08 · 10 years ago
Link
0 notes
arch497-08 · 10 years ago
Video
tumblr
Using a Piezo sensor to detect vibration. When detected have an alarm sound and a RGB led go off.
2 notes · View notes
arch497-08 · 10 years ago
Video
tumblr
Changing an RGB led with 4 Pots. One of them controlling White, another Red, another Green, then Blue respectively.
The Code:
/*
  AnalogReadSerial
  Reads an analog input on pin 0, prints the result to the serial monitor.
  Attach the center pin of a potentiometer to pin A0, and the outside pins to +5V and ground.
   This example code is in the public domain.
 */
int Red = 3;
int Green = 5;
int Blue = 6;
// the setup routine runs once when you press reset:
void setup() {
  // initialize serial communication at 9600 bits per second:
  Serial.begin(9600);
pinMode(Red, INPUT);
pinMode(Green, INPUT);
pinMode(Blue, INPUT);
}
// the loop routine runs over and over again forever:
void loop() {
 // int intValue1;
  //int redValue1;
  //int greenValue1;
  //int blueValue1;
     // read the input on analog pin 0:
  int intValue = analogRead(A0);
  int redValue = analogRead(A1);
  int blueValue = analogRead(A2);
  int greenValue = analogRead(A3);
  int intValue1 = map(intValue,0,1023,0,6);
     int redValue0 = (redValue*intValue1);
  int blueValue0 = (blueValue*intValue1);
  int greenValue0 = (greenValue*intValue1);
        int redValue1 = map(redValue0,0,5115,0,255);
  int blueValue1 = map(blueValue0,0,5115,0,255);
  int greenValue1 = map(greenValue0,0,5115,0,255);
        analogWrite(Red, redValue1);
  analogWrite(Green, greenValue1);
  analogWrite(Blue, blueValue1);
     // print out the value you read:
  Serial.print("Intensity");
  Serial.print(" ");
  Serial.print(intValue1);
  Serial.print(" + ");
  Serial.print("Red");
  Serial.print(" ");
  Serial.print(redValue1);
  Serial.print(" + ");
  Serial.print("Green");
  Serial.print(" ");
  Serial.print(greenValue1);
  Serial.print(" + ");
  Serial.print("Blue");
  Serial.print(" ");
  Serial.println(blueValue1);
     delay(1);        // delay in between reads for stability
}
1 note · View note
arch497-08 · 10 years ago
Video
tumblr
Midterm prototype
0 notes
arch497-08 · 10 years ago
Tumblr media
1 note · View note
arch497-08 · 10 years ago
Tumblr media
Eclipse: October 2014
0 notes
arch497-08 · 10 years ago
Video
tumblr
Controlling the position of a servo motor with a potentiometer
1 note · View note
arch497-08 · 10 years ago
Video
tumblr
1 note · View note
arch497-08 · 10 years ago
Video
tumblr
1 note · View note
arch497-08 · 10 years ago
Video
tumblr
Blinking an LED with a switch and a potentiameter.
1 note · View note
